6 | Electrical connection
80.06.083_iCombi Pro-iCombi Classic_IM_V01_en-US 57 / 84
Hz Power con-
sumption
(A)
Power (kW) Fuse (A) RCD model
6-1/1 G (1 NAC 230 V) 50/60 2.6 0.6 15 F
6-2/1 G (1 NAC 230 V) 50/60 3.9 0.9 15 B
10-1/1 G (1 NAC 230 V) 50/60 4 0.91 15 B
10-2/1 G (1 NAC 230 V) 50/60 6.3 1.46 15 B
20-1/1 G (1 NAC 230 V) 50/60 5.7 1.3 15 F
20-2/1 G (1 NAC 230 V) 50/60 9.3 2.15 15 B
Hz Power con-
sumption
(A)
Power (kW) Fuse (A) RCD model
6-1/1 G (1 NAC 240 V) 50/60 2.5 0.6 15 F
6-2/1 G (1 NAC 240 V) 50/60 3.8 0.9 15 B
10-1/1 G (1 NAC 240 V) 50/60 3.8 0.91 15 B
10-2/1 G (1 NAC 240 V) 50/60 6.1 1.46 15 B
20-1/1 G (1 NAC 240 V) 50/60 5.4 1.3 15 F
20-2/1 G (1 NAC 240 V) 50/60 9 2.15 15 B
Hz Power con-
sumption
(A)
Power (kW) Fuse (A) RCD model
6-1/1 G (2 AC 200 V) 50/60 1.9 0.38 15 B
6-2/1 G (2 AC 200 V) 50/60 3.3 0.65 15 B
10-1/1 G (2 AC 200 V) 50/60 3.8 0.75 15 B
10-2/1 G (2 AC 200 V) 50/60 6.3 1.25 15 B
20-1/1 G (2 AC 200 V) 50/60 6.0 1.2 15 B
20-2/1 G (2 AC 200 V) 50/60 9.5 1.9 15 B
Hz Power con-
sumption
(A)
Power (kW) Fuse (A) RCD model
6-1/1 G (2 AC 208 V) 60 2.9 0.6 15 B
6-2/1 G (2 AC 208 V) 60 4.3 0.9 15 B
10-1/1 G (2 AC 208 V) 60 4.3 0.9 15 B
10-2/1 G (2 AC 208 V) 60 7.2 1.5 15 B
20-1/1 G (2 AC 208 V) 60 6.3 1.3 15 B
20-2/1 G (2 AC 208 V) 60 10.6 2.2 15 B
Hz Power con-
sumption
(A)
Power (kW) Fuse (A) RCD model
6-1/1 G (2 AC 220 V) 50/60 2.7 0.6 15 B
6-2/1 G (2 AC 220 V) 50/60 4.1 0.9 15 B
10-1/1 G (2 AC 220 V) 50/60 4.1 0.9 15 B
10-2/1 G (2 AC 220 V) 50/60 6.8 1.5 15 B
