ONTENTS
C
Page
INTRODUCTION
Introduction 1
Special Definitions 1
PERIODIC MAINTENANCE
100-Hour Maintenance 2
2000-Hour Maintenance 2
TROUBLESHOOTING
Preparation 4
Tools Required 4
Before Starting 4
Error Messages 5
Basic Troubleshooting 6
Check Display Power 8
Check Weight Readout At Each Load Cell 9
Display Debug Mode 11
Hardware 13
Fork Assembly 13
Wire Harness 14
Load Cells 15
Display 16
Printer 18
SERVICE
Parameter Settings 19
Accessing The Parameters Menu 19
Changing A Parameter 20
Parameter Table 22
View Current Calibration Settings 26
Change Units 28
Reset Current Parameter and Calibration Settings To
Default (Factory) Settings 30
Three Part Calibration 31
Calibration Introduction 31
Prior To Calibration 32
Zero Calibration 33
Corner Calibration 35
Weight Calibration 41
Display 48
Pairing The Display To iForks 48
Wire Harness 52
Wire Harness Removal 52
New Wire Harness Installation 64
