Manual No. 016-0159-822 Rev E 45
INITIAL SYSTEM SETUP AND TESTING
INITIAL SYSTEM FIELD TEST
NOTE: This procedure applies only to applications of 3 GPM [11 lit/min] or greater. For flow less than 3 GPM
[11 lit/min], refer to the section for the alternate bypass line testing procedure.
1. Drive down the field at the target speed with the sprayer booms off to verify the SPEED readout in the console.
2. Turn on the sprayer and booms.
3. Switch the RATE switch to RATE 1.
4. Increase or decrease the vehicle’s speed by one MPH [2 km/h].
NOTE: The system should automatically adjust to the target application rate. If the system does not perform
the adjustment, perform the steps in . If the system is still not performing correctly, refer to for
possible causes and corrective action.
5. At the end of each row, switch the Master ON/OFF switch to OFF to shut off the flow. This also turns off the area
totalizer.
6. Verify the area covered and the volume used.
ALTERNATE BYPASS PLUMBING INITIAL SYSTEM FIELD TEST
NOTE: This procedure applies only to applications of less than 3 GPM [11 lit/min]. For flow of 3 GPM [11
lit/min] or greater, refer to the Initial System Setup section on page 43 for the main hose line testing
procedure.
1. Drive down the field at the target speed with the sprayer booms off to verify the SPEED readout in the console.
2. Turn on the sprayer and booms.
3. Switch the MAN/AUTO switch to AUTO.
4. Increase or decrease the vehicle’s speed by 1 MPH [2 km/h].
NOTE: The system should automatically adjust to the target application rate. If the system does not perform
the adjustment, perform the steps in the Alternate Bypass Plumbing Initial System Field Test section
on page 45. If the system is still not performing correctly, refer to Chapter 6 Preventative Maintenance
and Troubleshooting for possible causes and corrective action.
5. At the end of each row, switch the Master ON/OFF switch to OFF to shut off the flow. This also turns off the area
totalizer.
6. Verify the area covered and volume used.
