Raven SCS 460 User Manual

23
11) DATA LOGGER TRIGGER UNITS
a) Display will show DATA LOG TRIGGER UNITS FEET [METER] .
b) Depressing momentarily changes the display between DATA LOG TRIGGER
UNITS FEET [METER] and SEC . DATA LOGGER TRIGGER VALUE has been
programmed previously. (SEC means seconds has been chosed as the unit of measure.)
c) Momentarily depress to advance to DATA LOGGER.
10) DATA LOGGER TRIGGER VALUE
a) Display will show
DATA LOG TRIGGER VALUE 0 .
b) Enter the TRIGGER VALUE.
c) Momentarily depress to advance to DATA LOGGER TRIGGER UNITS.
6) GPS FILE REFERENCE
a) Display will show
GPS FILE REF 1 .
b) Enter the GPS file number
c) Momentarily depress to advance to GPS OPTIONS.
7) GPS OPTIONS
a) GPS is inactive when the display shows GPS INACTIVE . The GPS features
are explained further in the GRID APPLICATION SYSTEM MANUAL.
b) Momentarily depress to advance to FIELD REFERENCE.
8) FIELD REFERENCE
a) Display will show
FIELD REF 0 .
b) Enter the field number.
c) Momentarily depress to advance to BAUD RATE.
9) BAUD RATE
a) Display will show
BAUD RATE 9600 .
b) Depressing momentarily changes the display between BAUD RATE 9600 and
1200 .
c) Momentarily depress to advance to DATA LOGGER TRIGGER VALUE.
NOTE: The TRIGGER VALUE default value is "zero". This value must be changed
to a desired number ranging from 1-9999. The DATA LOGGER features will
not work if this number is not changed.
