Raven SCS 660 Installation And Service Manual

15
5) Displaying LI (liquid sprayer), GR1 (single bed belt), or GR2 (split bed belt).
a) Depressing momentarily
steps the DATA display from LI to GR1.
b) Depressing momentarily
steps the DATA display from GR1 to GR2.
c) Depressing momentarily steps the DATA display from GR2 to LI.
6) Selecting LI, GR1, or GR2.
a) To select GR1, or GR2, step
until desired code is displayed in the
DATA display.
NOTE: If a liquid application (LI) is desired, see the SCS 660 Liquid
Application Manual.
b) Momentarily depress
. The data display will now display C-Sd.
7) Displaying C-Sd (Standard Valve), C-F (Fast Valve), or C-FC (Fast Close Valve).
a) Momentarily depressing
steps the DATA display from C-Sd to C-F.
b) Momentarily depressing steps the DATA display from C-F to C-FC.
c) Momentarily depressing steps the DATA display from C-FC to C-Sd.
8) Selecting C-Sd, C-F, or C-FC.
a) To select C-Sd, C-F, or C-FC, step
until desired code is displayed
in DATA display.
b) Momentarily depress
. The DATA display will now display 0.
