22
11. ENTER MODE SEQUENCE WITH ACTIVATED DATA-LOCK
The DATA-LOCK feature prohibits the entry of data without first entering the DATA-
LOCK CODE. If DATA-LOCK is not desired, omit Steps 9, 10, and 11.
1) Depress the key into which you wish to enter data.
2) Depress
. CODE message will appear. Enter your DATA-LOCK CODE. If CODE
is correct, "E" will appear. Now enter data normally.
3) The DATA-LOCK CODE may be cleared by entering a code of "0" or by resetting the
Console. To RESET Console place POWER ON/OFF switch to OFF, depress
and
hold while placing the POWER ON/OFF switch to ON.
12. DATA MENU
The following are brief descriptions of features available under the DATA MENU
key (some features are only available on consoles with serial interface port):
DISPLAY
RATE DATA FEATURE and DESCRIPTION
Prn bEGn CONSOLE DATA PRINTOUT
Sends data through serial port to attached optional printer
to print field begin and field end pages (Serial interface
console only).
ALrn on AUDIBLE ALARMS ON/OFF
Turns audible alarms ON or OFF for the following:
1) Volume/Area Rate Alarm
2) Volume/Minute Rate Fault
3) Left Shaft Fault
4) Right Shaft Fault
5) Low Tank Fault
6) Bin Level Fault
diSP on DISPLAY SMOOTHING ON/OFF
Turns display smoothing ON or OFF. Selecting display
smoothing ON means the RATE window displays target rate when
actual rate is within a percentage of target rate. The third
digit of VALVE CAL determines this percentage.
FAn 0000 FAN RPM
Displays fan RPM in DATA window.
SHFT 1oFF LEFT SHAFT FAULT ON/OFF
Turns left shaft fault detector ON or OFF. When fault
detector is selected ON; alarm sounds and RATE display
flashes "SHA1" if left shaft should be rotating, but is not.
To Next Page
