23
DISPLAY
RATE DATA FEATURE and DESCRIPTION
SHFT 2oFF RIGHT SHAFT FAULT ON/OFF
Turns right shaft fault detector ON or OFF. When fault
detector is selected ON; alarm sounds and RATE display
flashes "SHA2" if right shaft should be rotating, but is not.
bin oFF BIN LEVEL FAULT ON/OFF
Turns bin level fault detector On or OFF. When fault
detector is selected ON; alarm sounds and RATE display
flashes "bin" if granular level drops below the bin level
sensor.
FCAL 0 FAN CALIBRATION
Displays and allows entering on fan calibration number.
rATE on RATE CHANGE ALARM ON/OFF
Turns rate change alarm ON or OFF. When rate change alarm
is selected ON; alarm sounds 4 long beeps when the rate 1
calibration number is changed via the serial port using a
valid change request data string (Serial interface console
only).
FILE 1 GPS FILE REFERENCE
Used only with Raven Grid Application System. See Grid
Application System manual for more details (Serial inter-
face console only).
GPS InAC GPS OPTIONS
Used only with Raven Grid Application System. See Grid
Application System manual for more details (Serial inter-
face console only).
FrEF 0 FIELD REFERENCE
Allows user to enter up to a four-digit number to represent
a field. Field reference is included in field begin and
field end pages and the data logger time/date string (Serial
interface console only).
bAUd 1200 BAUD RATE
Used in GPS mode and data logging mode. Selectable between
1200 or 9600 baud (Serial interface console only).
TriG 0 DATA LOGGER TRIGGER VALUE
Used in data logging mode. The trigger determines how often
actual rate data string (See Appendix 6 for data communi-
cation string formats) is sent to the serial port. The
trigger may be either feet [meters] or seconds (Serial
interface console only).
