Chartapplication’sorientationeverythingonthechartwillrotate,
includingthetext.Asrasterchartsareascannedimagethele
sizeisnormallybiggerwhencomparedtothevectorequivalent.
Vectorcharts
Vectorchartsarecomputergenerated,consistingofaseries
ofpointsandlinesthatmakeupthechart.Chartobjectsand
overlaysonvectorchartscanbeswitchedonandoffand
chartobjectscanbeselectedtoprovidefurtherinformation.
Ranginginandoutofvectorchartswillmakegeographical
featuresappearlargerorsmalleronthescreen,howevertext
andchartobjectswillremainthesamesizeregardlessofrange.
WhenchangingtheChartapplication’sorientationgeographical
featureswillrotatebuttextandchartobjectswillremainin
thecorrectorientationforthedisplay.Asvectorchartsare
generatedratherthanascannedimagethelesizeisnormally
smallerwhencomparedtotherasterequivalent.
DownloadingLightHouse
TM
charts
LightHouse
TM
chartscanbedownloadedthroughtheRaymarine
website.
Important:YoumustreadandagreetotheLightHouse
TM
chartsEndUserLicenseAgreement(EULA)before
downloadingandusingLightHouse
TM
charts.
1.GototheLightHousechartspageoftheRaymarinewebsite:
http://www.raymarine.com/lighthousecharts/.
2.SelecteithertheRasterorVectorcharts.
TheChartregionspageisdisplayed.
3.Selectyourregion.
Thechartregiondownloadpageisdisplayed.
4.Click‘Viewthetermsofuse’.
5.ReadandensureyouFULLYunderstandtheEndUser
LicenseAgreement(EULA).
Youshouldonlyproceedtothenextstepifyouagreetothe
termsoftheEULA.
6.Enteryourdetailsintherelevantelds.
7.Clickthecheckboxagainst‘Ihavereadandagreetothe
LightHouseChartstermsofuse.
8.ClickDownloadChart.
Thedownloadshouldstartautomatically.Alinkisprovidedif
thedownloaddoesnotcommence.
Note:
•Duetothelesizethedownloadmaytakesometime.
•Downloadtimeswilldifferdependingonconnectionspeed.
•Asthelesarelargeitisrecommendedthatyouusea
downloadmanager/acceleratorwhichcanspeedupyour
downloadtimeandensurethatifthedownloadfailsthe
downloadcanberesumedratherthandownloadingthe
entireleagain.
9.Waitforthedownloadtonish.
Thedownloadedlecannowbeunzipped/extractedtomemory
cardforusewithyourmultifunctiondisplay.
