90
HSB Series Chartplotter
5.4 Chart Set Up Parameters
The CHART SET UP option allows you to set up the chartplotter
according to your system configuration and your personal preferences.
The following table lists the Chart Set up parameters and their options,
shows the factory default setting, and provides a space for you to make
a note of your new default setting. Each parameter is described in the
following subsections.
Parameter Options Factory New
Default Default
CUSTOMISE See below for details
CHART
PLOTTER MODE OFF ON
ON
CHART ORIENTATION NORTH UP NORTH UP
COURSE UP
HEAD UP
OBJECT INFORMATION OFF ON
ON
WAYPOINT OFF ON
ON
WAYPOINT NUMBERS OFF OFF
ON
DEFAULT WAYPOINT Fish, skull, X
SYMBOL X or anchor symbol
HEADING VECTOR OFF, 3 MINS, 10 MINS OFF
INFINITE
COG VECTOR OFF, 3 MINS, 10 MINS OFF
INFINITE
TIDE VECTOR OFF, 10 MINS, 1 HOUR OFF
INFINITE
RADAR/CHART OFF OFF
SYNCH ON
DATUM SELECTION WGS 84, LOCAL WGS 84
Chart
Set Up
Parameters
