HSB Series Chartplotter
6.8 System Check and Initial Switch On
Once you have installed your Chartplotter and made all the connections,
you need to check your installation before using the system for
navigation. If you encounter any problems, refer to Chapter 7.
You may wish to read Chapters 2, 3 and 4, and familiarise yourself with
the operation of the Chartplotter, before performing the initial set up.
System Check
Before performing the functional test, check the following:
• All securing bolts are fully tightened and mechanical locking
arrangements as specified are in place
• All connections have been made
• All connecting wires are secured and protected as necessary
Note: If you are the boat owner and have performed the installation
yourself, ask your authorised installation dealer to check the installation
before going to sea.
Initial Switch On
To switch on the display unit, press and hold the POWER key until the
unit beeps.
If the display switches on in Radar (following a magnetron warm-up
sequence) or Data Log mode, press DISPLAY to show the Display pop-
up. Press DISPLAY again, as necessary, to select Chart mode, then
press ENTER.
If necessary, adjust the lighting and contrast (see Section 2.2).
If required, change the default language settings as follows:
1. Press the MENU key to display the setup soft key labels.
D3640-3
2. Press the SYSTEM SET UP soft key.
The SYSTEM SET UP menu is displayed, listing the parameters and
their current settings. The complete list, which you can scroll down, is
shown in the following illustration.
System Check
and
Initial Switch On
To Next Page
