96
HSB Series Chartplotter
6.2 Unpacking and Inspecting the Components
Unpack your HSB Series Chartplotter carefully, to prevent damage to
the equipment. It is good practice to save the carton and packing for
future use, in case you need to return any units for service.
Check that you have all the correct system components. These depend
on your system package, as follows:
Item Part No. Supplied Option
with: for:
7” LCD Display M92670 Light grey:RL70RC -
M92733 Dark grey:RL70RC -
R32005 Light grey:RC520 -
R32007 Dark grey:RC520 -
7” LCD Display Accessories
Sun cover (light grey) D331 Light grey:RL70RC, -
RC520 -
Sun cover (White) D356 Dark grey: RL70RC, -
RC520 -
Handbook, Radar 81149 RL70RC -
Handbook, Chart 81150 All -
Quick Reference Card, Radar 86032 RL70RC -
Quick Reference Card, Chart 86033 All -
Mounting bracket assy. W143 All -
Trunnion knobs (x2) W145 All -
Flush mount kit M92708 - All
Power cable W144 All -
Seatalk cable assembly
Flat moulded plugs both ends:
1m (3ft 3in) long W284 - All
3m (9ft 9in) long W285 - All
5m (16ft 3in) long W286 - All
9m (29ft 3in) long W287 - All
Flat to male round connector:
0.3m (12in) long D187 - All
Flat to female round connector:
0.3m (12in) long D188 - All
Flat moulded plug one end only:
1m (3ft 3in) long D229 - All
Ferrite clamp R55007 - All
Seatalk junction box D244 - All
Seatalk auxilliary junction box R55006 RL70RC, RC520 -
HSB cable assy
- 1m R55001 - All
- 3m R55002 - All
- 6m R55003 - All
- 10m R55004 - All
NMEA OUT cable assy. 1.5m R55005 All -
Unpacking and
Inspecting the
Components
