100
HSB Series Chartplotter
you only need to connect NMEA In to the master display, which will pass
the data to the repeater via SeaTalk.
Note: To transfer NMEA data, the display must be powered ON.
The following paragraphs describe these data standards and define the
data that is transferred. The diagrams on the following pages show
examples of integrated systems: the first includes SeaTalk instruments
and an HSB repeater display; the second example shows NMEA
instruments and an HSB repeater display.
Data Standards
HSB
The High Speed Bus (HSB) provides extremely rapid transfer of data
between master and repeater displays. Any two devices that conform to
the HSB standard can be inter-connected. With an HSB and a SeaTalk
connection most data available can be controlled and displayed by either
unit (Guard zones cannot be viewed or controlled on the chartplotter
display, nor on a repeater display that is not directly connected to a
scanner. Likewise, radar timed transmission is not available on a repeater
display).
For example, you could connect an HSB Radar display and an HSB
Chartplotter display, to enable you to display and control both radar and
chart data on either or both displays. The HSB series displays allow you to
select either type of data for display, or display both types at the same
time, in half-screen windows.
When two displays are used, the following functionality will be obtained at
each display (assuming a radar scanner is connected to Display 1)
Scanner Display 1 Display 2
Connected Type Functionality Type Functionality
No RC520 Chart master RL70 Chart repeater
No RC520 Chart master RC520 or Chart master
Chart repeater(disp.2) RL70RC Chart repeater (disp.1)
Display 1 RL70RC Radar master RL70 Radar repeater
Chart master Chart repeater
Display 1 RL70RC Radar master RC520 or Chart master
Chart master RL70RC Chart repeater (disp. 1)
Chart repeater (disp.2)
Display 1 RL70 Radar master RL70 Radar repeater
Display 1 RL70 Radar master RC520 or Chart master
Chart repeater RL70RC Radar repeater
Data
Standards
