104
HSB Series Chartplotter
* If Magnetic Heading is not available, the True Heading and Variation (if available) are
used to generate the magnetic heading.
The HSB series chartplotter display unit transmits the following data, if
available, on either SeaTalk or NMEA Out:
Data Output SeaTalk NMEA
Position ✔ GGA GLL RMC
Speed Over Ground and ✔ RMC VTG
Course Over Ground
Waypoint Identifier ✔ APB BWC RMB
Bearing to Waypoint ✔ APB BWC RMB
Distance to Waypoint ✔ BWC RMB
Cross Track Error (XTE) ✔ APC RMB
Depth ✔ —
Apparent Wind Angle and Speed ✔ —
Boat Speed Through Water ✔ —
Total Log and Trip Log ✔ —
Water Temperature ✔ —
Heading ✔ —
Magnetic Variation ✔ —
Time ✔ BWC GGA GLL RMC ZDA
Date ✔ RMC ZDA
MOB data ✔ —
Cursor Position ✔ —
EBL/VRM Positions — —
Heading mode — —
Radar display range — —
SeaTalk and
NMEA Data
Transfer
