Chapter 1: Introduction 3
Dedicated
keys
Trackpad
Soft keys
Dedicated keys
D4266-1
The HSB (High Speed Bus) connection enables transfer of data
between two compatible units. For example, the chart data is transferred
from the chartplotter (the master display) via the HSB connection and
can be displayed
and controlled
on any other HSB display (repeater
display). In particular, you can connect your HSB Series Chartplotter to a
remote HSB Series Radar to provide similar functionality to the
combined Radar/Chartplotter.
Full functionality of the HSB Series Chartplotter is achieved when it is
part of an integrated system, with other equipment (in addition to another
HSB unit) connected via Seatalk or NMEA 0183. Data from this
equipment including position, waypoints and routes, is displayed on the
chartplotter and is used in calculations. Details on connecting other
equipment are given in Chapter Six.
