BS06K SERIES 6kW All-In-One Smart Laser Cutting Head-User Manual
2.4 Inspection of Top Cover Glass (1
st
Installation/Replacement of Fiber)
Maintenance or repair shall be implemented at dust free workstation.
▪ Loose bolts (item 1) and pull out the glass holder until you see the complete cover glass.
▪ Seal the openings of cutting head by textured tape immediately.
▪ Check if the top cover glass is clean. If not, blow the cover glass by clean compressed air until it is clean.
The cover glass shall be replaced if it cannot be cleaned or a damage happens.
