Raytools BS06K Series - Technical Data

V1.0 Raytools AG © Copyright 4 |24
www.raytools.ch
BS06K SERIES 6kW All-In-One Smart Laser Cutting Head-User Manual
1.3 Technical Data
Model
BS06K
Wavelength
1080nm
Fiber Interface
QBH/G5
Power Rating
6kW
Optical Configuration
- Collimation Length (fC)
- Focusing Length (fF)
100mm
200mm
NA
0.13
Auto Focus Range (Vertical)
-52...+32mm
Beam Alignment Range
-1.5mm…+1.5mm
Installation - Screw QTY and Size
Mounting Plate
Preamplifier
4xM6.6
4xM3
Cutting Gas
Φ10, max. 25bar
Nozzle Cooling Gas
Φ8, max. 5bar
Water Cooling
Φ6, max. 5bar, min. 1.5L/min
Operating Voltage
24V±10%, max. 4A
I/O Interface (19-Pin)
Output current must be less than 30mA
Operating Temperature
5
℃～
55
℃
Humidity
30％～95％, without condensing
Weight
6.5kg～7.0kg
