RCm MEGA 732 - Confi Gurazione Dip Switch; Dip Switch Confi Guration

70
Carica batterie - CBHF2-B 24V 25A confi gurazione dip switch “ fi g.11/A.
Nelle seguenti tabelle sono riporati tutti i settaggi dei dipswitch per la programmazione del carica batterie CBHF2-B 24 25A.
DIP 7 DIP 8 VB
ON ON
12
►OFF ON 24
DIP 1 DIP 2 DIP 3 DIP 4 CURVA DI CARICA
ON ON ON ON 0 (Curva per batterie al GEL tipo SONNENSCHEIN, DETA e altri costruttori).
►OFF ON ON ON 1 (Curva per batterie a trazione al PIOMBO-ACIDO [con liquido]).
ON OFF ON ON 2
OFF OFF ON ON 3
ON ON OFF ON 4
OFF ON OFF ON 5
►ON OFF OFF ON 6 (Curva per batterie al PIOMBO-ACIDO E GEL (sigillate) tipo TROJAN e altri costruttori).
OFF OFF OFF ON 7
ON ON ON OFF 8
OFF ON ON OFF 9
ON OFF ON OFF 10
►OFF OFF ON OFF 11 (Curva per batterie al GEL tipo SONNENSCHEIN, DETA e altri costruttori).
ON ON OFF OFF 12
OFF ON OFF OFF 13
ON OFF OFF OFF 14
OFF OFF OFF OFF 15
DIP 5 DIP 6 CORRENTE
ON ON 15A
OFF ON 20A
ON OFF 25A
DIP 5, DIP 6, con CURVA DI CARICA 11 selezionata.
DIP 7, DIP 8, per la selezione del votaggio batteria.
DIP 1, DIP 2, DIP 3, DIP 4 per la selezione della CURVA DI CARICA.
DIP 1 DIP 2 DIP 3 DIP 4 CHARGING CURVE
ON ON ON ON 0 (Curve for GEL batteries from SONNENSCHEIN, DETA and other manufacturers).
►OFF ON ON ON 1 (Curve for LEAD-ACID [Wet] traction batteries).
ON OFF ON ON 2
OFF OFF ON ON 3
ON ON OFF ON 4
OFF ON OFF ON 5
►ON OFF OFF ON 6 (Curve for Sealed LEAD-ACID and GEL batteries from TROJAN and other manufacturers).
OFF OFF OFF ON 7
ON ON ON OFF 8
OFF ON ON OFF 9
ON OFF ON OFF 10
►OFF OFF ON OFF 11 (Curve for GEL batteries from SONNENSCHEIN, DETA and other manufacturers).
ON ON OFF OFF 12
OFF ON OFF OFF 13
ON OFF OFF OFF 14
OFF OFF OFF OFF 15
Battery charger - CBHF2-B 24V 25A dip switch confi guration “ fi g.11/A.
In the following tables you can fi nd meaning of all different position of dipswitch for programming CBHF2-B 24 25A battery charger.
DIP 5 DIP 6 CURRENT
ON ON 15A
OFF ON 20A
ON OFF 25A
DIP 7 DIP 8 VB
ON ON 12
►OFF ON 24
DIP 5, DIP 6, for the selection of the CURRENT 11.
DIP 7, DIP 8, for the selection of the battery voltage.
DIP 1, DIP 2, DIP 3, DIP 4 for the selection of the CHARGING CURVE
