RCm TERA 1102 - Page 19

19
TECHNICAL DATA 1/3
TERA Versions 1102 - 1102 T 1102 R/1 - 1102 RT 1303 - 1303 T
Performance
Maximum hourly washing capacity 8800 m²/h 8800 m²/h 10400 m²/h
Cleaning width 1100 mm 1100 mm 1300 mm
Drying width 1360 mm 1360 mm 1360 mm
Max. travel speed 9 km/h
Max. reverse speed 4.5 km/h
Max. working speed 8 km/h
Max. gradient 16%
Noise level (EN ISO 11201/2010)
Sound pressure level in operating position dB(A) 68,4
Vibrations (EN ISO 13754/2008)
Level of the frequency-weighted accelerations m/s² < 2,5
Brushes
Brush (no.- type) 2 - disc 2 - roller 3 - disc
Position Between front and rear wheels
Turning speed (RPM) 160-170 840-880 160-170
Lifting electric
Diameter 560 mm
170 mm (front)
490 mm
200 mm (rear)
Pressure (weight) 0-115 kg 0-115 kg
0-90 kg
Waste container
Capacity 30 L
Squeegee
Type  oating
Vacuum (squeegee vacuum) mm/H2O 1500
Lifting and lowering electric
Tanks
Clean water (solution) 280 L
Dirty water (recovery) 305 L
Steering
Type with steering wheel/mechanics on front wheel
Minimum space for U-turn 2550 mm
Electric motors
Drive motor 1 - 36 V - 2000 W
Brush rotation motor 2 - 36 V - 400 W 2 - 36 V - 600 W 3 - 36 V - 400 W
Vacuum motor 2 - 36 V - 580 W
Total power 3960 W 4360 W 4360 W
