RCm TERA 1102 - Page 20

20
(TERA 1102 - 1102 T) (TERA 1102 R/1 - 1102 RT | 1303 - 1303 T)
2060 mm
2060 mm
1360 mm
1550 mm
1360 mm
1550 mm
TECHNICAL DATA 2/3
TERA Versions 1102 - 1102 T 1102 R/1 - 1102 RT 1303 - 1303 T
Machine weight
Weight when empty (without operator - without battery) 677 kg 672 kg 712 kg
Weight when empty (without operator - with battery) 1280 kg 1275 kg 1315 kg
Weight (without operator - with solution tank full and battery) 1560 kg 1555 kg 1595 kg
Batteries
Battery (type) equipped with automatic top-up and distilled water tank
No./V/Ah 1 - 36 - 525
Dimensions (length X width x height) 620 x 610 x 555 mm
Peso | Weight | Poids | Gewicht 603 kg
Battery water distilled water
*Battery life (h) with machine in STANDARD MODE and front drive 4.40’ 4.40’ 4.10’
*Battery life (h) with machine in GO GREEN MODE and front drive 6 6 5.20’
*Battery life (h) with machine in STANDARD MODE and rear drive 5.45’ 5.45’ 5
*Battery life (h) with machine in GO GREEN MODE and rear drive 7.40’ 7.40’ 6.30’
*Battery life may vary, depending on the type of battery and the use of the machine
Drive
Position
front / forward and reverse drive with
electronic control and drive selector
Wheels
Super-elastic front rubber wheel Ø 350 mm
Super-elastic rear rubber wheel Ø 375 mm
Brakes
Position on rear wheels
Service brake (type)
mechanical drum ( versions 1102 T - 1102 RT - 1303 T )
hydraulic drum ( versions 1102 - 1102 R/1 - 1303 )
Electric brake Electric on front drive wheel
Dimensions (without brushes)
