RDM EC9001f - Inside the Front Cover and Endorsement Printer Cover

To Next Page

To Previous Page

EC9000i / 9100i / 9600i Series Scanner User Guide Models and features

Inside the front cover and endorsement printer cover - top view

Exit pocket

Magnetic

stripe reader

(MSR)

Document track

Franker

Back

Front (extensions retracted)

Insertion hopper

Image sensor

and panels

(closed)

ID card entry imaging

slot

Scanner LED

Metal post for top cover

Metal post for

top cover

Endorsement printer

(select models)

RDM EC9001f - Inside the Front Cover and Endorsement Printer Cover - Top View
