EC9000i / 9100i / 9600i Series Scanner User Guide Operating the scanner
Light signals and beeps
The scanner’s status is shown through a single, multistate LED (light-emitting diode), which is the light on
the top, front, right-hand side of the unit. The table below describes typical status signals and their
meanings.
Signals Meaning
Red-red-green-green flashing
cycle
During start up, the scanner is being configured by the application.
Wait for the application to finish configuring the scanner.
Red-green flashing cycle
Green solid The scanner is ready and idle.
Green flashing The scanner is waiting for the user to insert a document into the
feeder.
Green-red flashing cycle The scanner is processing the document. Wait for the scanner to
finish.
Red flashing with one beep An error occurred while the scanner was processing the document.
Check your PC application for instructions or refer to your local
procedures. If you need more help, contact your distributor (reseller).
Green flashing with one short
beep
The scanner read the document successfully.
Red flashing and three short
beeps
The scanner was not able to read the MICR line.
A typical document processing / LED cycle
1. The LED is Green (Solid): The unit is idle.
2. The LED is Green (Flashing): The scanner is waiting for a document to be inserted for scanning.
3. The LED is Green/Red (Flashing): The scanning operation is in progress.
4. The LED is Green (Solid): The scanning operation is complete. The scanner has returned to its
idle state.
©2015 RDM Corporation Page 24
