5. Installing the Work Switch
The work switch signals to the app when the implement is in or out of the ground.
Figure 15: Work switch
Provided Parts
Part Name
Part Number
Quantity
Work switch assembly
353070-000534
1
Tools Needed
• None
Installation Location
Installed in a location where the work switch tilts from one end to the other when the toolbar is
changing from raised to lowered positions.
Figure 16: Work switch mounting location
