8. Installing Harnessing
The wiring harnesses provide power from the tractor to Recon Blockage Plus™.
NOTE: The gateway uses the tractor's key switch for proper operation. Make sure that the key
switch is wired to the key switch terminal of the 3-pin power outlet in the tractor cab.
Part Name
Part Number
Quantity
4 Pin sealing plug
153510-000051
2
Cable tie
355032-000004
varies
20’ ECU harness
353050-000097
1/ECU
Power harness
353050-000098
1 (tow-behind cart) or
2 (tow-between cart)
10’ ECU harness
(dual-shoot systems only)
353050-000099
1/ECU
Tractor harness
353050-000100
1
Gateway harness
353050-000101
1
Gateway extension harness
(tow-between carts only)
353050-000103
2
3 pin CAN terminator plug
356070-000104
2
Tools Needed
• None
Installation Location
Refer to Appendix A for wiring diagrams for your implement type.
Installing 10’ ECU Harnesses (353050-000099) (dual-
shoot only)
NOTE: If you have a single shoot system, skip this step.
1. Connect S2 of a 10’ ECU harness (353050-000099) to each 4-pin connector on a
Product A ECU.
2. Connect S3 of a 10’ ECU harness to 4-pin connector on each Product B ECU near it.
Installing 20’ ECU Harnesses (353050-000097)
1. Connect S3 of a 20’ ECU harness (353050-000097).
• Dual-shoot: Connect S3 of a 20’ ECU harness to S1 of each 10’ ECU harness.
• Single-shoot: Connect S3 of a 20’ ECU harness to each ECU’s 4-pin connector.
2. Locate the two centermost ECUs, then connect the gateway harness.
a. Connect S4 of the gateway harness to S1 of the left-center 20’ ECU harness
b. Connect S3 of the gateway harness to S1 of the right-center 20’ ECU harness.
