1. Introduction
About Recon Blockage Plus™
Intelligent Ag’s Recon Blockage Plus is an acoustic-based monitoring system that quickly and
accurately notifies operators of blockages anywhere in their implement. Operators interact with
the system via an iPad® app in the tractor cab.
For instructions to use the system after installation, see the Recon Blockage Plus Operator’s
Guide from the app’s Guides screen.
For current documentation, iPad and software requirements, and other resources, visit
intelligentag.com/support.
Required Tools and Equipment
You will need the following tools and equipment to install Recon Blockage Plus:
• Standard wrench and socket sets
• Measuring tape
• Cutting tool, such as a PEX tubing cutter, box cutter, or shears
• Pliers
• Phillips screwdriver
• Cordless drill and/or flathead screwdriver (optional)
• Paint pen or other permanent marking tool (optional)
Installation Overview
ESTIMATED INSTALL TIME: 6 hours
□ Install flow sensors
□ Install ECUs
□ Connect auditory tubes to ECUs
□ Install work switch
□ Install gateway
□ Install Wi-Fi antenna
□ Install harnessing
□ Install iPad mount and download app
