RED DEVIL 1400 - Wiring Diagrams; 1400-X1 Model Wiring Diagram

14
Owner’s Manual:1400 & 1410
1787021 REV D
ECO 16-0082
May 2017
Air & Explosion
www.radiaproducts.com (PHONE) 800-221-1083 | (INTL) +1-763-533-2969 | (FAX) 763-533-0015
C
BROWN
WHITE
RELAY
120V 5784622
EXPLOSION PROOF MOTOR 5784615
RED
1
4
8
2
0
6
GREEN START
P/B (N/O)
RED STOP
P/B (N/C)
LINE 1 LINE 2 GROUND
SUPPLY FUSE OR BREAKER
RED
BLACK
BROWN
MOTOR AND RELAY
WIRING DETAIL
FROM MACHINE
PUSH BUTTON CONTROL STATION
PART NUMBER 5784642
Mounted by end user
GREEN
GREEN
WHITE
BLACK
5784065
LIMIT SWITCH (N/O)
RED
RED
BROWN
BLUE
WHITE
B/W
WHITE
BROWN
RED
BLUE
GREEN
GREEN
CONDULET BODY, L
9785153
CONDUIT BOX, T
9785155
GREEN
THERMAL O/L
7. Wiring Diagrams
7.1 1400-X1 Model Wiring Diagram
