RED DEVIL 1400 - Clamp Assembly Right; Right Clamp Assembly Parts

21
Owner’s Manual:1400 & 1410
1787021 REV D
ECO 16-0082
May 2017
Air & Explosion
www.radiaproducts.com (PHONE) 800-221-1083 | (INTL) +1-763-533-2969 | (FAX) 763-533-0015
12
11
10
9
2
6
7
8
1
3
4
5
12
11
10
9
2
6
7
8
1
3
4
5
ID Description
19784820 CLAMP JAW, RIGHT FRONT - 54XX
29784819 CLAMP JAW, RIGHT REAR - 54XX
39188100 HANDLE, CLAMP, 5400
49785071 WASHER, LOCK, INTERNAL TOOTH, M12
59785072 NUT, HEX JAM, M12X1.75
69784830 CLAMP SCREW - 14XX
79782216 Thrust Washer
ID Description
8 9140200 Key, Woodru No 404
9 9690800 SCREW, HEX 3_8-16 X 2.00
10 9161100 Washer, Flat 3_8 USS
11 9780402 Washer 3_8 split lock
12 6784823 ASSY, GUIDE ROD, HD - 14XX
13
6785101 - Right Side Assembly Kit13
8.6 Clamp Assembly Right
...Exploded Views, Continued
PART NUMBERS LISTED MAY ONLY BE AVAILABLE IN KIT FORM OR AS AN ASSEMBLY
Exploded Views, Continued..
