Remote And Local Setpoint Operation
The controller setpoint mode can be switched between Local Setpoint
operation and Remote Setpoint operation. In the Hidden Function Mode, the
“SPSL” parameter allowsthe operatorto selectthe desired setpointoperating
mode. To allow front panel switching between setpoint modes, program the
setpoint select parameter (SPSL) to “Enbl” in the Lockout Module. The user
input or RS485 serial interface option may also be used to perform the
setpoint selection function, independent of the setting in the Lockout
Module. Front panel annunciator REM is on for Remote setpoint operation
and isoff forLocal setpoint operation.When transferringthe controllermode
from/tothe setpoint modes, various controllerresponse options are available
(see SPtr parameter, p age 38 ).
