Configure Module 6 - Serial Communications (6-SC)
Unit returns to configuration access point if RS485 serial option is not installed.
Display Parameter
Range and Units
(Factory Setting
Value)
Description/
Comments
bAUd Baud rate 300 to 9600
(1200)
Baud rate of unit
must match
connected
equipment.
PArb Parity bit odd, even, no parity
(odd)
Parity of unit must
match other
equipment.
Add Unit address 0 to 99
(0)
For multiple units,
each unit must have
a unique address.
Abr Abbreviated or full
transmission
yes/no
(no)
Selecting yes, the
controller does not
transmit
mnemonics.
PrAt Auto print rate 0 to 9999
(0)
0 disables auto print
function
PoPt Print options yes/no
(no)
Selecting yes allows
print options shown
below, to be
programmed.
INP Input Temperature yes/no
(yes)
SEt Setpoint yes/no
(yes)
OPr % Output Power yes/no
(yes)
Pdb % Proportional Band yes/no
(no)
INt Integral Time yes/no
(no)
dEr Derivative Time yes/no
(no)
AL1 Alarm 1 yes/no
(no)
AL2 Alarm 2 yes/no
(no)
Display Parameter
Range and Units
(Factory Setting
Value)
Description/
Comments
dEv Deviation From
Setpoint
yes/no
(no)
OFP % Output Power
Offset
yes/no
(no)
r_P Setpoint Ramp Rate yes/no
(no)
Crg Cooling Relative
Gain
yes/no
(no)
Cdb Cooling Deadband yes/no
(no)
OSt Output Status yes/no
(no)
rAt Remote Setpoint
Ratio
yes/no
(no)
bIA Remote Setpoint
Bias
yes/no
(no)
Pb2 Secondary
Proportional Band
yes/no
(no)
It2 Secondary Integral
Time
yes/no
(no)
dt2 Secondary
Derivative Time
yes/no
(no)
RSP Remote Setpoint yes/no
(no)
SP2 Secondary Directed
Setpoint
yes/no
(no)
IN2 Second Analog Input yes/no
(no)
HCr Heater Current yes/no
(no)
To Next Page
