Configure Module 3 - Lockout Parameters (3-LC)
Display Parameter
Range and Units
(Factory Setting
Value)
Description/
Comments
SP Setpoint access LOC - lockout
rED - read only
Ent - enter
(Ent)
Determines access to
temperature setpoint.
OP Output power
access
LOC - lockout
rED - read only
Ent - enter
(Ent)
Determines direct
access to output power.
%PW indicator
illuminates when
parameter is selected in
display.
dEv Deviation LOC - lockout
rEd - read only
(rEd)
Determines display of
deviation. DEV indicator
illuminates when
parameter is selected in
display.
IN-2 Second Analog
input
LOC - lockout
rEd - read only
(rEd)
Determines display of
Second Analog input
(Remote Setpoint)
(SEC illuminates)
Hcur Heater Current LOC - lockout
rEd - read only
(rEd)
Determines display of
Heater Current
(CUR illuminates).
UdSP Units display LOC - lockout
rEd - read only
(rEd)
Determines display of F
or C
Code Access code 0 to 250
(0)
Refer to front panel
disable section for
access levels.
PId PID values
enable
LOC - lockout
rEd - read only
Ent - enter
(LOC)
Protected mode lockout.
PId2 Secondary PID
values enable
LOC - lockout
rEd - read only
Ent - enter
(LOC)
Protected mode lockout.
Cascade only.
Display Parameter
Range and Units
(Factory Setting
Value)
Description/
Comments
rtbS Remote Setpoint
Ratio & Bias
LOC - lockout
rEd - read only
Ent - enter
(LOC)
Remote Setpoint Ratio
and Bias values enable
AL Alarm values
enable
LOC - lockout
rEd - read only
Ent - enter
(LOC)
Protected mode lockout
ALrS Reset alarms
enable
LOC - lockout
ENBL - enable
(LOC)
Hidden mode lockout
SPSL Remote/Local
setpoint select
enable
LOC- lockout
ENBL - enable
(LOC)
Hidden mode lockout
trnF Automatic/Manual
(user) mode
select enable
LOC - lockout
ENBL - enable
(LOC)
Hidden mode lockout
tUNE Auto-tune enable LOC- lockout
ENBL - enable
(LOC)
Hidden mode lockout
