Page #13 background imageLoading...
Page #13 background image
APPROVED DSMC2 EXTERNAL DC POWER
The WEAPON, SCARLET-W, RAVEN, and EPIC-W accept input voltages of 11.5 V to 17 V DC, and can draw a
maximum current of 9 A. The camera can be powered continuously by connecting one (1) of the following to an
attached module or expander:
DSMC AC Power Adaptor
RED BRICK Charger: Offers two (2) ways to connect to your camera:
Use a RED ONE DC Power Cable (P/N 790-0060) and a 2B-to-1B Power Adaptor Cable (P/N 790-0138).
Use a RED 2B-to-1B LEMO Power Cable (P/N 790-0556).
RED BRICK: Requires a DSMC2 V-Lock I/O Expander, Battery Belt Clip (DSMC), or DSMC2 V-Lock Battery
Module Pro. Also supported by a RED Quickplate or RED Cradle using a 2B-to-1B Power Adaptor Cable.
REDVOLT-V: Requires a DSMC2 V-Lock I/O Expander, Battery Belt Clip (DSMC), or DSMC2 V-Lock Battery
Module Pro. Also supported by a RED Quickplate or RED Cradle using a 2B-to-1B Power Adaptor Cable.
XLR DC power source: Requires an XLR Power Cable.
WARNING: While third-party batteries may be mechanically compatible with the camera system, the manufacturer is
responsible for the performance and stability of third-party options, not RED. Damage to the camera system or third-
party devices caused by using third-party power options is not covered under warranty. The camera may be unable to
determine and display the voltage or remaining battery capacity of third-party power options.
C OPYRI G HT © 2017 RED.C OM , LLC 955- 0038, REV-AD| 13
RED DSMC POWER OPERATION GUIDE
