APPROVED EPIC/SCARLET EXTERNAL DC POWER
The EPIC/SCARLET accepts input voltages of 11.5 VDC to 17 VDC, and can draw a maximum current of 12 A. The
camera can be powered continuously by connecting one (1) of the following to the DC IN port on the EPIC/SCARLET:
DSMC AC Power Adaptor
RED BRICK Charger: Offers two (2) ways to connect to your camera:
Use a RED ONE DC Power Cable (P/N 790-0060) and a 2B-to-1B Power Adaptor Cable (P/N 790-0138).
Use a RED 2B-to-1B LEMO Power Cable (P/N 790-0556).
RED BRICK: Requires a Backpack Quickplate or Battery Belt Clip (DSMC). Also supported by a RED Quickplate
or RED Cradle using a 2B-to-1B Power Adaptor Cable.
REDVOLT-V: Requires a Backpack Quickplate or Battery Belt Clip (DSMC). Also supported by a RED Quickplate
or RED Cradle using a 2B-to-1B Power Adaptor Cable.
XLR DC power source: Requires an XLR Power Cable.
WARNING: While third-party batteries may be mechanically compatible with the camera system, the manufacturer is
responsible for the performance and stability of third-party options, not RED. Damage to the camera system or third-
party devices caused by using third-party power options is not covered under warranty. The camera may be unable to
determine and display the voltage or remaining battery capacity of third-party power options.
DSMC2 POWER OPERATIONS
This section describes the basic power operations for WEAPON, SCARLET-W, RAVEN, and EPIC-W cameras.
DSMC2 POWER INPUTS
NOTE: The WEAPON, SCARLET-W, RAVEN, and EPIC-W BRAINs themselves do not have DC IN power ports. A port
expander or power module is required to power each camera.
The following devices have DC IN ports:
DSMC2
®
REDVOLT XL Module
DSMC2 Base Expander
DSMC2 V-Lock I/O Expander
DSMC2 Jetpack Expander
DSMC2 Jetpack-SDI Expander
DSMC2 REDVOLT Expander
DSMC2 V-Lock Battery Module Pro
C OPYRI G HT © 2017 RED.C OM , LLC 955- 0038, REV-AD| 11
RED DSMC POWER OPERATION GUIDE
