BACKPACK QUICKPLATE (SHORT) MODULE
SPECIFICATION DESCRIPTION
Dimensions Height: 4.29" (109 mm)
Width: 3.54" (90 mm)
Depth: 1.28" (33 mm)
Weight Approximately 0.82 lbs (371 g), Module only
Construction Aluminum Alloy
Operating Temperature 0°C to 4C (3F to 104°F)
Storage Temperature 20°C to 50°C (F to 12F)
Connectors AUX 1 (2-pin 0B LEMO)
AUX 2 (2-pin 0B LEMO)
DSMC2 POWER MODULES
This section provides the technical specifications for DSMC2
®
power modules.
DSMC2 REDVOLT XL MODULE
SPECIFICATION DESCRIPTION
Dimensions Height: 4.69" (119 mm)
Width: 4.09" (103.8 mm)
Depth: 1.69" (43 mm)
Weight 1.00 lbs (453 g)
Material Aluminum
Mounting 4x M4 captive mounting screws
BRAIN/Expander Connection Power delivery via DSMC2 Rear pogo connector (13-Pin)
Battery Compatibility REDVOLT XL
Operating Temperature 0°C to 4C (3F to 104°F)
Storage Temperature 2C to 50°C (–4°F to 122°F)
Operating Humidity 0% to 85%, non-condensing
Storage Humidity 0% to 85%, non-condensing
Firmware Requirement Compatible with all DSMC2 firmware versions
C OPYRI G HT © 2017 RED.C OM , LLC 955- 0038, REV-AD| 84
RED DSMC POWER OPERATION GUIDE
