RED DSMC SIDE HANDLE User Manual

REDVOLT XL MODULE
SPECIFICATION DESCRIPTION
Dimensions Height: 4.29" (109 mm)
Width: 4.41" (112 mm)
Depth: 1.52" (39 mm)
Weight Approximately 0.94 lbs (425 g), Module only
Construction Aluminum Alloy
Operating Temperature 0°C to 40°C (32°F to 104°F)
Storage Temperature –20°C to 50°C (–4°F to 122°F)
Connectors CHARGE IN (6-pin 1B LEMO)
AUX POWER OUT (2-pin 0B LEMO)
Firmware Requirement DSMC firmware v5.1.29 or later
QUICKPLATE MODULE
SPECIFICAITON DESCRIPTION
Dimensions Height: 4.29" (109 mm)
Width: 4.41" (112 mm)
Depth: 1.52" (39 mm)
Weight Approximately 0.70 lbs (317 g), Module only
Construction Aluminum Alloy
Operating Temperature 0°C to 40°C (32°F to 104°F)
Storage Temperature –20°C to 50°C (–4°F to 122°F)
Connectors AUX 1 (2-pin 0B LEMO)
AUX 2 (2-pin 0B LEMO)
Firmware Requirement DSMC firmware v5.1.14 or later
C OPYRI G HT © 2017 RED.C OM , LLC 955- 0038, REV-AD| 83
