RED DSMC SIDE HANDLE User Manual

+1 ADAPTOR MODULE
SPECIFICATION DESCRIPTION
Dimensions Height: 4.29" (109 mm)
Width: 3.54" (90 mm)
Depth: 0.87" (22 mm)
Weight Approximately 0.75 lbs (349 g), Module only
Construction Aluminum Alloy
Operating Temperature 0°C to 40°C (32 to 104°F)
Storage Temperature –20°C to 50°C (–4°F to 122°F)
Connectors RED
®
EVF/LCD
PWR (4-pin 0B LEMO
®
), 2.0 Amp continuous load at 11.5-17 VDC
Firmware Requirement DSMC firmware v4.0.8 or later
WARNING: DO NOT use the EVF/LCD port on the +1 Adaptor Module if a Pro I/O Module is connected to the
DSMC
®
BRAIN
®
.
PRO BATTERY MODULE (DUAL)
SPECIFICATION DESCRIPTION
Dimensions Height: 4.29" (109 mm)
Width: 3.86" (98 mm)
Depth: 2.65" (67 mm)
Weight Approximately 1.21 lbs (549 g), Module only
Construction Aluminum Alloy
Operating Temperature 0°C to 40°C (32°F to 104°F)
Storage Temperature –20°C to 50°C (–4°F to 122°F)
PRO BATTERY MODULE (QUAD)
SPECIFICATION DESCRIPTION
Dimensions Height: 4.29" (109 mm)
Width: 3.86" (98 mm)
Depth: 4.35" (111 mm)
Weight Approximately 1.65 lbs (748 g), Module only
Construction Aluminum Alloy
Operating Temperature 0°C to 40°C (32°F to 104°F)
Storage Temperature –20°C to 50°C (–4°F to 122°F)
C OPYRI G HT © 2017 RED.C OM , LLC 955- 0038, REV-AD| 82
RED DSMC POWER OPERATION GUIDE

RED DSMC SIDE HANDLE Specifications

General

Brand	RED
Model	DSMC SIDE HANDLE
Category	Camera Accessories
Language	English
