RED DSMC POWER OPERATION GUIDE
A
TECHNICAL
SPECIFICATIONS
EPIC/SCARLET POWER MODULES
This section provides the technical specifications for EPIC/SCARLET
®
power modules.
DSMC SIDE HANDLE
SPECIFICATION DESCRIPTION
Dimensions Height: 4.96" (126 mm)
Width: 2.76" (70 mm)
Depth: 3.31" (84 mm)
Weight Approximately 1.01 lbs (458 g), Module only
Construction Aluminum Alloy
Operating Temperature 0°C to 40°C (32°F to 104°F)
Storage Temperature –20°C to 50°C (–4°F to 122°F)
MODULE ADAPTOR
SPECIFICATION DESCRIPTION
Dimensions Height: 4.29" (109 mm)
Width: 3.54" (90 mm)
Depth: 0.87" (22 mm)
Weight Approximately 0.61 lbs (278 g), Module only
Construction Aluminum Alloy
Operating Temperature 0°C to 40°C (32°F to 104°F)
Storage Temperature –20°C to 50°C (–4°F to 122°F)
