DSMC2 V-LOCK BATTERY MODULE
SPECIFICATION DESCRIPTION
Dimensions Height: 4.57" (116.0 mm)
Width: 3.71" (94.3 mm)
Depth: 1.42" (36.0 mm)
Weight 0.79 lbs (356 g)
Material Aluminum
BRAINMounting 4x M4 captive mounting screws
BRAINConnections Power delivery via rear pogo connector (13-Pin)
Connectors P-Tap Aux Power output (2-Pin), 3.0A
Battery Compatibility RED BRICK and other standard V-Lock batteries
Operating Temperature 0°C to 40°C (32°F to 104°F)
Storage Temperature –20°C to 50°C (–4°F to 122°F)
Operating Humidity 0% to 85%, non-condensing
Storage Humidity 0% to 85%, non-condensing
Firmware Requirement Compatible with DSMC2 firmware v6.2 or later
DSMC2 V-LOCK BATTERY MODULE PRO
SPECIFICATION DESCRIPTION
Dimensions Height: 4.57" (116.0 mm)
Width: 4.06" (103.1 mm)
Depth: 1.51" (38.3 mm)
Weight 0.824 lbs (374 g)
Material Aluminum Alloy
BRAIN Mounting 4x M4 captive mounting screws
BRAIN Connections Power delivery via rear pogo connector (13-Pin)
Connectors
DCIN (6-Pin 1B LEMO socket)
P-Tap Aux Power output (2-Pin), 3.8 A shared
Aux Power output (2-Pin 0B LEMO), 3.8 A shared
Battery Compatibility RED BRICK, REDVOLT-V, and other standard V-Lock batteries
Operating Temperature 0°C to 40°C (32°F to 104°F)
Storage Temperature –20°C to 50°C (–4°F to 122°F)
Firmware Requirement Compatible with all DSMC2 firmware v6.3.102 or later
C OPYRI G HT © 2017 RED.C OM , LLC 955- 0038, REV-AD| 85
RED DSMC POWER OPERATION GUIDE
