DSMC2 REDVOLT XL MODULE INDICATOR LEDS
The DSMC2 REDVOLT XL Module indicator LEDs display information about the current state of an equipped
REDVOLT XL Battery when the module is used as a desktop charging station. Refer to the following table for
information about the different REDVOLT XL charging states.
COLOR/FLASHING DESCRIPTION
Green Battery is fully charged
Green flashing Charging; half second on, half second off
Green/Red flashing Lamp self test at power up; half second red, half second green
Green/Red flashing
(alternating)
Error; alternating, half second green, half second red, repeat
Red flashing Battery discharge alert; heartbeat (red) pulse once per minute indicates that the battery is
discharging and should be removed from module
1
1. The DSMC2 REDVOLT XL Module draws a small amount of power any time a battery is attached, when there is no charging source available.
CHARGE WITH THE DSMC2 REDVOLT XL MODULE
The DSMC2 REDVOLT XL Module can charge one (1) REDVOLT XL battery, but only when the camera is off. When the
camera is on, power is drawn from the battery rather than the attached power supply, resulting in a net loss of power.
The DSMC2 REDVOLT XL Module can fully charge a discharged REDVOLT XL in approximately four (4) hours.
To charge a REDVOLT XLbattery with the DSMC2 REDVOLT XL Module, follow the instructions below:
1. Turn off the camera.
2. Attach the protective baseplate to the DSMC2 REDVOLT XL Module.
3. Connect the DSMC AC Power Adaptor to the DC IN port on the DSMC2 REDVOLT XL Module.
NOTE: The battery does not charge if the power source is connected to the DCINport on the BRAIN.
4. Insert a REDVOLT XL battery into the DSMC2 REDVOLT XL Module.
WARNING: DO NOT use the DSMC2 REDVOLT XL Module as a desktop charger without the protective baseplate to
cover the rear connectors. This may cause irreparable damage to the rear connectors on the module and is not
covered under warranty.
C OPYRI G HT © 2017 RED.C OM , LLC 955- 0038, REV-AD| 52
