REDVOLT-V LED ARRAY
The REDVOLT-V battery LED array consists of three (3) LEDs and a status button. Press the status button to illuminate
the LEDs, displaying the remaining battery charge level in 33% steps.
LED PATTERN DESCRIPTION
Three (3) LEDs are on 71% to 100% capacity remaining
Two (2) LEDs are on 41% to 70% capacity remaining
One (1) LED is on 11% to 40% capacity remaining
One (1) LED flashes for three (3) seconds 0% to 10%capacity remaining
The two (2) outside LEDs flash for three (3) seconds Battery error
1
Three (3) LEDs are off Battery is discharged and requires charging
1. To resolve the error, charge the battery. If you still receive the error after charging the battery, submit a Technical Support request at
https://support.red.com.
C OPYRI G HT © 2017 RED.C OM , LLC 955- 0038, REV-AD| 66
RED DSMC POWER OPERATION GUIDE
