BRAIN LEDS
This section describes the LED functions for the camera.
NOTE: When the camera is powered only by battery and not AC power, the Power Status LED (PWR) on the
expander or module does not turn on. You can press the button on the battery to check the battery charge
level.
LED COLOR/FLASHING DESCRIPTION
Power Status LED
(PWR)
Off No power present; camera off
Green Power present; camera on
Amber flashing Power present; 5–10 min of battery time available
Amber Power present; camera booting
Red flashing Power present; < 5 min of battery time available
Record Status LED
(REC)
Off No media present
Green Ready to record
Amber Finalizing
Red flashing (slow) Media mounted with > 5% and ≤ 10% of media space
available
Red flashing (fast) Media mounted with ≤ 5% of media space available
Red Recording
Power Status LED (PWR)
and Record Status LED (REC)
Both green flashing Firmware update in progress
Both red flashing Firmware update error
