RED WEAPON Series - Appendix A: Technical Specifications; WEAPON 6 K (Carbon Fiber) Specifications

COPYRIGHT © 2016 RED.COM, INC
RED DSMC OPERATION GUIDE: WEAPON/SCARLET-W
955-0116_V6.1, REV-U | 162
WEAPON 6K (CArbON FibEr)
WEAPON 6K (CArbON FibEr) TECHNiCAL SPECiFiCATiONS
SPECiFiCATiON DESCriPTiON
Sensor Type RED DRAGON
®
19.4 Megapixel CMOS
Effective Pixels 6144 (h) x 3160 (v)
Sensor Size 30.7 mm (h) x 15.8 mm (v) x 34.5 mm (d)
Dynamic Range 16.5+ stops
Signal-to-Noise Ratio 80 dB
Max Data Rates Up to 300 MB/s using RED MINI-MAG (512GB and 1TB)
Up to 225 MB/s using RED MINI-MAG (120GB and 240GB)
Max Frame Rates Go to “WEAPON (Carbon Fiber) Frame Rates” on page 78 for a full list
Playback Frame Rates (Project
Time Base)
23.98, 24, 25, 29.97, 47.96, 48, 50, 59.94, 60 FPS, all resolutions
REDCODE
®
Settings Range
from 2:1 up to 22:1
1
To see all of the maximum available REDCODE values, see the DSMC Media
Operation Guide at www.red.com/downloads
REDCODE RAW
Acquisition Formats
Go to “WEAPON Formats” on page 83 for a full list
Apple
®
ProRes Apple ProRes 422 HQ up to 4K (4096 x 2160) and up to 29.97 FPS
Apple ProRes 422 up to 4K (4096 x 2160) and up to 29.97 FPS
Apple ProRes 422 LT up to 4K (4096 x 2160) and up to 29.97 FPS
Apple ProRes 4444 XQ up to 2K (2048 x 1080) and up to 120 FPS
Apple ProRes 4444 up to 2K (2048 x 1080) and up to120 FPS
Apple ProRes 422 HQ up to 2K (2048 x 1080) and up to 120 FPS
Apple ProRes 422 up to 2K (2048 x 1080) and up to 120 FPS
Apple ProRes 422 LT up to 2K (2048 x 1080) and up to 120 FPS
Construction Carbon Fiber, Magnesium, and Aluminum Alloy
Weight WEAPON Forged CF: 3.3 lbs (BRAIN only)
WEAPON Woven CF: 3.27 lbs (BRAIN only)
Operating Temperature 0˚C to 40˚C (32˚F to 104˚F)
Storage Temperature –20˚C to 50˚C (–4˚F to 122˚F)
A
TECHNICAL
SPECIFICATIONS
