RED DSMC OPERATION GUIDE: WEAPON/SCARLET-W
COPYRIGHT © 2016 RED.COM, INC 955-0116_V6.1, REV-U | 83
AUTO SLATE
Frame values for Auto Head Frames and Auto Tail Frames on the Auto Slate tab, these values only show in-camera.
The Auto Head Frames and Auto Tail Frames metadata values are currently disabled in REDCINE-X PRO.
FORMAT
Use the Format menu to select the resolution, aspect ratio, anamorphic setting, and lookaround setting. The
available aspect ratios are determined by the selected resolution.
After selecting format settings, select Set Format.
WEAPON FORMATS
The table below describes the formats for each of the following cameras:
WEAPON (Carbon Fiber)
WEAPON (Magnesium)
The table below omits rows for the anamorphic formats, since the pixel dimensions for each anamorphic format
and the corresponding non-anamorphic format are the same. For more information, go to “Anamorphic” on
page 88.
The camera offers a 6:5 aspect ratio for each resolution. Using a 6:5 aspect ratio at 2x anamorphic gives you
a 2:40:1 aspect ratio.
RESOLUTION DIMENSIONS (PIXELS) DIMENSIONS (MM)
WIDTH HEIGHT WIDTH HEIGHT DIAGONAL
6K FF 6144 3160 30.72 15.80 34.55
6K 2:1 6144 3072 30.72 15.36 34.35
6K 2.41:1 (WS) 6144 2592 30.72 12.96 33.34
6K 16:9 (HD) 5568 3132 27.84 15.66 31.94
6K 3:2 4752 3160 23.76 15.80 28.53
6K 6:5 3792 3160 18.96 15.80 24.68
6K 4:1 6144 1536 30.72 7.68 31.67
6K 8:1 6144 768 30.72 3.84 30.96
5.5K FF 5632 2948 28.16 14.74 31.78
5.5K 2:1 5632 2816 28.16 14.08 31.48
5.5K 2.41:1 (WS) 5632 2376 28.16 11.88 30.56
5.5K 16:9 (HD) 5376 3024 26.88 15.12 30.84
5.5K 4:1 5632 1408 28.16 7.04 29.03
5.5K 8:1 5632 704 28.16 3.52 28.38
5K FF 5120 2700 25.60 13.50 28.94
5K 2:1 5120 2560 25.60 12.80 28.62
5K 2.41:1 (WS) 5120 2160 25.60 10.80 27.78
5K 16:9 (HD) 4800 2700 24.00 13.50 27.54
5K 6:5 3240 2700 16.20 13.50 21.09
5K 4:1 5120 1280 25.60 6.40 26.39
5K 8:1 5120 640 25.60 3.20 25.80
