RED DSMC OPERATION GUIDE: WEAPON/SCARLET-W
COPYRIGHT © 2016 RED.COM, INC 955-0116_V6.1, REV-U | 179
HDMI OUT
The following expanders feature an HDMI 1.2 (Type A) connector:
DSMC
2
Base Expander
DSMC
2
Base I/O V-Lock Expander
DSMC
2
Jetpack Expander (for more information about HDMI wireless transmitter support, go to “HDMI
Wireless Transmitters” on page 179)
A standard HDMI connector provides the following output:
High-definition video output (default mode is Overlay)
Two (2) channels of embedded audio
The HDMI output provides the formats described in the table below:
HDMI OUTPUT FORMATS
1
VIDEO FEED
2
FREQUENCY (HZ)
480p 50.00, 60.00
720p 24.00, 25.00, 30.00, 50.00, 60.00
1080p 24.00, 25.00, 30.00, 50.00, 60.00
1. Ensure you select a frequency supported by your monitor.
2. The HDMI output is progressive scan (p); it does not support progressive segmented frame (PsF) or interlaced (i) scan formats.
COMPATIBLE CABLE
790-0331: RED HDMI Cable (5')
HDMI WIRELESS TRANSMITTERS
The HDMI connector supports HDMI wireless transmitters, so that you can transmit the HDMI signal to a remote
HDMI monitor. The HDMI connector supports industry-standard HDMI wireless transmitters.
NOTE: The DSMC
2
Jetpack Expander features a spring-loaded retainer that keeps a mounted HDMI wireless
transmitter firmly in place. A wireless transmitter that is longer than 9.8 cm (including the HDMI connector)
might not fit in the retainer.
NOTE: The DSMC
2
Jetpack Expander and DSMC
2
Base I/O V-Lock Expander have a USB power out connector that
provides 5 V at 1.5A, which powers most industry-standard HDMI wireless transmitters. For more information,
go to “USB Power” on page 185.
