RED DSMC OPERATION GUIDE: WEAPON/SCARLET-W

COMPATIBLE LENS TYPE FOCAL LENGTH

Sigma APO Sigma APO 120-300mm f/2.8 EX DG OS HSM

Sigma APO 180mm f/2.8 Macro EX DG OS HSM

Tamron Tamron SP 10-24mm f/3.5-4.5 Di II

Tamron SP 15-30mm f/2.8 Di VC USD

Tamron SP 24-70mm f/2.8 Di VC USD

Tokina Tokina AT-X 116 Pro DX, 11-16mm f/2.8 SD IF DX

Tokina AT-X 116 Pro DX-II, 11-16mm f/2.8 SD IF DX

Zeiss Distagon

Zeiss Distagon T* 15mm f/2.8 ZE

Zeiss Distagon T* 18mm f/3.5 ZE

Zeiss Distagon T* 21mm f2.8 ZE

Zeiss Distagon T* 25mm f/2 ZE

Zeiss Distagon T* 28mm f/2 ZE

Zeiss Distagon T* 35mm f2 ZE

Zeiss Makro-Planar

Zeiss Makro-Planar T* 100mm f/2 Z

Zeiss Planar Zeiss Planar T* 50mm f1.4 ZE

Zeiss Planar T* 85mm f1.4 ZE

Zeiss Otus

Zeiss Otus 55mm f/1.4

NIKON F-MOUNT LENSES

This section describes the appropriate method for attaching and detaching Nikon

F-Mount lenses. For more

information, refer to the original manufacturer’s instructions. This section also lists lenses supported by the

DSMC Nikon F-Mount.

WARNING: ALWAYS protect your equipment, when it is not in use, by replacing lens caps and mount caps.

ATTACH NIKON F-MOUNT LENSES

1. Rotate the secondary locking ring counter-clockwise to disengage.

2. Press the lens release button and rotate the lens cap clockwise to remove the camera mount cap.

3. Remove the rear lens cap.

4. Align the mounting index (white dot) on the lens with the mounting index on the DSMC Nikon mount and

position the lens in the bayonet mount.

5. Rotate the lens counter-clockwise until it clicks into place, being careful to NOT press the lens release

button.

6. Rotate the secondary locking ring clockwise to engage.

DETACH NIKON F-MOUNT LENSES

1. Rotate the secondary locking ring counter-clockwise to disengage.

2. Press and hold the lens release button. While holding the lens release button, turn the lens clockwise until

it stops and remove it from the camera mount.

3. Replace the rear lens cap and camera mount cap when items are not in use.
