Regency P36E-NG4 - Regency Series Combustible Mantel Clearances

P36E-4 Zero Clearance Direct Vent Gas Fireplace 13
Drywall
12" Mantel
7 1/2" Mantel
3 1/2"
Mantel
Mantel Clearances with
Flush Glass / Full Screen Doors
14"
7"
10"
30-1/2"
to floor
2
0
12
6
4
810
2
0
12
6
16
4
14
8
10
Side View
Top of
Unit
30-1/2"
to floor
2
0
12
6
4
810
12" Mantel
7 3/4“ Mantel
3 1/2"
Mantel
Mantel Clearances
with Bay Option
13"
2
0
12
6
16
4
14
8
10
Drywall
Top of
Unit
7"
10"
Side View
6" Standoff
6" Standoff
Because of the extreme heat this fi replace emits, the mantel clearances are critical.
Combustible mantel clearances from top of unit are shown in Diagrams 1 & 2.
REGENCY
®
SERIES COMBUSTIBLE MANTEL CLEARANCES
These drawings are to scale at 1:6 (one inch = 6 inches)
Mantel can be installed anywhere in shaded area or higher using the above scale.
Note: Ensure the paint that is used on the mantel and the facing is "heat resistant" or the paint may discolour.
Note: A non-combustible mantel may be installed at a lower height if the framing is made of metal studs covered with a non-combustible
board.
Diagram 1
Diagram 2
INSTALLATION
