Regency P36E-NG4 - Safety Label; Copy of Safety Decal

P36E-4 Zero Clearance Direct Vent Gas Fireplace
6
This is a copy of the label that accompanies
each P36E Zero Clearance Direct Vent
Gas Fireplace. We have printed a copy
of the contents here for your review. The
safety label is located on the front inside
base of the unit, visible when the bottom
louver is open.
NOTE: FPI units are constantly being
improved. Check the label on the unit and
if there is a difference, the label on the unit
is the correct one.
SAFETY LABEL
DO NOT REMOVE THIS LABEL / NE PAS ENLEVER CETTE ÉTIQUETTE
360
360
DOOR SEAL: Please
check that the door is
properly sealed
Minimum Clearances to Combustibles /
Degagement Minimum De Materiaux Combustibles
Serial No./ No de serie
918-853
The "Bay Louvers" be
used with the Bay Glass option
MUST
MAY BE INSTALLED IN MANUFACTURED (MOBILE) HOMES AFTER FIRST SALE.
Duplicate S/N
B
B
32"
Ceiling
Wall
Wall
A
0" Clearance to combustibles from: Mantel Clearances from Top: Side Wall Clearance from Side Facing Alcove Clearances: Minimum Vent Clearances: Top, sides, bottom and rear of unit (A) Min. 7" (177mm) B) 6" with Flush or Bay Front B) 8" with Barcelona Trim Alcove approved for Bay & Flush Louvers. Max. Depth 36" (914mm) Min. Width 48" (1219mm), Min. Height 72" (1229mm) Vertical Vent 1-1/4" (32mm) Horizontal Top 2" (51mm) Horizontal Side 1-1/2" (38mm) Horizontal Bottom 1-1/2" (38mm)
(See Instruction Manual for detailed instructions)
ÉÉQUIP A L'UISINE POUR GAZ PROPANE
PROPANE GAS: Model P36E-LP4
11” WC/C.E. (2.73 kPa) 10" WC/C.E. (2.49 kPa) 6.4" WC/C.E. (1.59 kPa)
Minimum supply pressure Manifold pressure High Manifold pressure Low
Pression d'allimentation minimum Pression la tubulure d' chappement lev e Pression la tubulure d' chappement basse
àééé àé
28,500 Btu for altitude 0 - 4500 ft. Maximum Input Minimum Input Orifice size Altitude
28,500 Btu/h (8.35 Kw/h) 22,000 Btu/h (6.44 Kw/h)
#52 DMS
0-4500 ft/pi (0-1372m)
D bit Calorifique maximum D bit Calorifique minimum Dimensions de l'orifice L'altitude
é é
Minimum supply pressure Manifold pressure high Manifold pressure low Orifice size Minimum input Maximum input Altitude
NATURAL GAS: Model P36E-NG4
APPAREIL FONCTIONNANT AU NATURAL GAS CONCU POUR ETRE POELE: Mod le P36E-NG4 Pression d'allimentation minimum Pression à la tubulure d' chappement lev e Pression à la tubulure d' chappement basse Grandeur de l'injecteur D bit minimum selon D bit maximum selon l'altitude
Calorifique Calorifique
é
ééé é
é é
5” (1.25 kPa) 3.5" (0..87 kPa) 1.6" (0.27 kPa) #37 DMS 0-4500 ft/pi (0-1372 m)
WC/C.E.
WC/C.E. WC/C.E.
19,500 Btu/h (5.71 kW) 29,500 Btu/h (8.65 kW)
This appliance must be installed in accordance with local codes, if any; if none, follow the National Fuel Gas Code, ANSI Z223.1, or Natural Gas and Propane Installation Code, CSA B149.1. This appliance must be installed in accordance with the Standard CAN/CSA Z240 MH, Mobile Housing, in Canada, or with the Manufactured Home Construction and Safety Standard, Title 24 CFR, Part 3280, in the United States, or when such a standard is not applicable,ANSI/NCSBCS A225.1/NFPA501A,Manufactured Home Installations Standard This appliance is only for use with the type of gas indicated on the rating plate and may be installed in an aftermarket, permanently located, manufactured (mobile) homewhere not prohibited bylocal codes. See owner'smanual for details. LP Conversion Kit #514-972 Installer l'appareil selon les codes ou règlements locaux, ou, en l'absence de tels règlements, selon les codes d'installationANSI Z223.1, National FuelGas Code ou CSA-B149.1 en vigueur. Installer l'appareil selon la norme CAN/CSA-Z240, Série MM, Maison mobiles ou CAN/CSA-Z240 VC, Véhicules de camping, ou la norme 24 CFR Part 3280, Manufactured Home Construction and Safety Standard. Si ces normes ne sont pas pertinentes, utilisez la normeANSI/NCSBCSA225.1/NFPA 501A, Manufactured Home Installations Standard. For use with glass doors certified with the appliance only This vented gas fireplace heater is not for use with air filters. Ne pas utiliser de filtre à air avec ce foyer au gazà évacuation.
Fan (Part # 432-917) Optional Bay Window (Part #510-930) Option:HeatWave Kit # 946-556
Electrical supply /Électrique 115VAC, 1.13A, 60Hz.
Cet appareil doit être utilize uniquement avec le type de gaz indiqué sur la plaque signalétique. Cet appareil peut être installé dans une maison préfabriquée ou mobile (É.-U. seulement) installée à demeure si les règlements locaux le permettent. Voir lanotice de l'utilisateur pourplus de renseignements. Cetappareil ne peut pasêtre utilisé avec d'autresgaz sauf si unetrousse de conversion certifiée est fournie.
Pour utilisation uniquement avec les portes en verre certifiées avec l'appareil
Made in Canada/
Fabrique au Canada
FPI Fireplace Products International Ltd.Delta, BC, Canada
Listed: Certified for/Certifi e pour: Tested to: WN# 16546
CANADA and U.S.A.
CAN/CGA-2.17-M91, ANSI Z21.88-2009 / CSA 2.33-2009
VENTED GAS FIREPLACE HEATER / FOYER AU GAZ À ÉVACUATION
é
VENTED GAS FIREPLACE HEATER - NOT FOR USE WITH SOLID FUELS.
NE PAS UTILISER AVEC DUCOMBUSTIBLE SOLIDE.FOYER AU GAZ À ÉVACUATION -
For the State of Massachusetts, installation
and repair must be done by a plumber or
gasfi tter licensed in the Commonwealth of
Massachusetts.
For the State of Massachusetts, fl exible
connectors shall not exceed 36 inches in
length.
For the State of Massachusetts, the appli-
ances individual manual shut-off must be a
t-handle type valve.
The State of Massachusetts requires the
installation of a carbon monoxide alarm in
accordance with NFPA 720 and a CO alarm
with battery back up in the same room where
the gas appliance is installed.
