Regency P36E-NG4 - Tripoli Screen Door

P36E-4 Zero Clearance Direct Vent Gas Fireplace 61
TRIPOLI SCREEN DOOR
REGENCY
®
OPTIONS
When installing the optional Tripoli Screen Door Series, a non-combustible material 12" (305mm) above the unit and 6" (153mm)
on each side must be used (see Diagram 1).
The Tripoli Screen Door Series also requires steel stud framing above and on each side of the unit (refer to Diagram 1).
Min. 361/4”
(921mm)
Steel
Stud
Steel
Stud
Min. 14-1/4" (362mm)P36
Min. 18-5/8" (473mm)P36D
Option #2:
Fireplace with 1" (25mm) Facing Material
Steel
Stud
Steel
Stud
Min. 12"
(305mm)
Min. 6"
(153mm)
Min. 6"
(153mm)
P36
36-1/4"
(921mm)
36-1/4"
(921mm)
Framing & Mantle/Side Materials
Arch Screen
Non - Combustible
Material
27-1/2”
(699mm)
30 -7/8”
(784mm)
P36D
376-1/4"
(946mm)
Diagram 1
Min. 14-1/4" (362mm)P36
Min. 361/4”
(921mm)
Steel
Stud
Steel
Stud
Min. 18-5/8" (473mm)P36D
Option #1:
Fireplace with 1-1/2" (38mm) Facing Material
INSTALLATION NOTE:
The hearth material must be brought past the Tripoli frame all the way to the unit
face, so there will be no gap between the face and the actual fi replace.
* 'D' is Minimum height to combustible materials including the Minimum 2" (51mm) Top clearance to the Horizontal Vent.
OPTIONS
FRAMING DIMENSIONS
P36E
ABCD
1 36-1/4”
(921mm)
36-1/4”
(921mm)
14-1/4”
(362mm)
46”*
(1168mm)
2 36-1/4”
(921mm)
36-1/4”
(921mm)
13-3/4”
(349mm)
46”
(1168mm)
