P36E-4 Zero Clearance Direct Vent Gas Fireplace
60
REGENCY
®
OPTIONS
3) Install the hinges to the hinge brackets on the left and right side of the
bottom of the outer frame, secure using 2 x #8 Philips Head Screws
per hinge.
4) Place the Bottom Grill near hinge. Flip the hinge over the Bottom
Grill and secure with 3 x #8 Philips Head Screws per side.
Bottom Grill
Hinge Location
Burner ON/OFF
Control Box
5) Mount the Burner ON/OFF Control Box to the left side of the Bottom
Grill using 2 x #8 Philips Head Screws.
Bottom
Grill
6) Slide the Top Grill into the louver brackets located on the inside top
of the fi rebox. Push in place.
Top Grill
8) Close screen doors.
7) Install the Left and Right Side Screen Doors in the fully open position
by placing over top of the hinges on the Full Screen Door Frame.
NOTE: Failure to install the doors in the fully open position could
result in paint damage to the surface of the door.
Hinge
Screen Door
