56
1. Select Edit Mobile Band from the Mode Settings Menu in the upper left corner of the screen or
tap on the frequency range at the bottom of one of the bars. The Mobile Bands Edit dialog will
appear.
2. From this dialog, Start and Stop frequencies of each range can be edited. Tap the frequency to
be edited. Frequency bands cannot overlap. If a Start or Stop frequency is edited so that it
overlaps another band, the affected frequencies will be highlighted in red. The settings will
require adjustment before they can be applied.
3. Additionally, for each band there is an Enabled checkbox. When this checkbox is de-selected,
the band will be removed from the display.
4. Each band can also be given a custom name using the "Band Name/#" column. This name will
appear above each band on the Mobile Bands screen.
5. When finished making changes, select the “x” in the upper right corner of the dialog. A dialog
box will ask for confirmation of saving the desired changes.
6. If any of the edits change the frequency order of the bands, use the Sort By Freq button to
reorder the bands from the lowest frequency to the highest frequency.
7. To return to the factory default values, select Restore Defaults from the bottom right of the
dialog.
8. To discard any changes made during the editing session, select Clear Changes from the bottom
right of the dialog.
Saving/Recalling Mobile Band Configurations
The MESA allows custom mobile band configurations to be saved and recalled for a later time.
To save a custom mobile band configuration:
1. Select Edit Mobile Band from the Mode Settings Menu or tap on the frequency range at the
bottom of one of the bars to enter the Mobile Bands Edit dialog.
2. Configure the settings to be saved.
3. Ensure that a USB thumb drive (see note on pg. 100) is in one of the USB ports.
4. Select Export Bands from the bottom of the Mobile Bands Edit dialog.
To recall a previously saved mobile band configuration:
1. Ensure that a USB thumb drive with the saved configuration is in one of the USB ports.
2. From the Mobile Bands Edit dialog, select Import Bands.
3. From the file manager window, select the desired configuration file and press Open.
