ASSEMBLY, INSTALLATION AND OPERATION
9
Feeding and Tabbing Media
The operating sequence of the T-250 Tabber is to first turn on the Main Power Switch,
and then press the reset button on the counter located on the top of the Tabber. Next,
activate the Tab Switch located next to the piece counter. Lastly, press the Feed Switch
to start the media feeding. To Stop the Tabber press the Feed Switch.
Troubleshooting
Problem Possible Cause
1. Media does not feed properly Improper setup of separator bar.
Glazed or dirty feed rollers.
Side Guides too tight.
2. Media skews when feeding Side Guides too loose.
Separator bar not set evenly.
3. Tab placement inconsistent Tabs not threaded correctly.
Tabs not centered in front of sensor holder
centerline.
Tab Roll is loose on spindle.
Rollers dirty or glazed.
4. Tab placement moves side to side Side guides loose.
Moveable post/Sensor Holder not set properly.
Problem Possible Cause
5. Multiple tabs placed on media Tabs not centered in front of sensor holder
centerline.
Tab sensitivity adjustment incorrect.
6. Media feeds without tabs. Tab Feed Switch not turned ON.
Out of Tabs.
Tab sensitivity adjustment incorrect.
Tab Pressure knob in OFF position.
Tabs not peeling off backing.
7. Tab sensitivity LED does not
illuminate
Power not on. (Perform tab sensitivity
adjustment.)
8. Power not on Unit not plugged in.
Fuse blown.
9. Tabs stream feed Tab Pressure knob in OFF position.
