Renault TRAFIC 2024 - Page 363

WIPER BLADES: REPLACEMENT
6
Practical advice - 361
Position the blade 3 of the wiper arm
1 at an angle of 30°.
Slide the blade along the arm until it
clips on. Check that it is correctly
locked. Lower the windscreen wiper
arm carefully.
Withtheignitionon,returnthewind
screen wiper stalk to the stop position.
Check the condition of the
wiperblades.Youarere
sponsible for their service
life:
– clean the blades, windscreen
and rear screen regularly with
soapy water;
– donotusethemwhenthewind
screen or rear screen is dry;
– free them from the windscreen
or rear screen when they have
not been used for a long time.
Rear screen wiper blade on rear
hinged doors
– Lift the wiper arm 4 ;
– pivot the blade 5 until you meet
some resistance;
– pullthebladetoreleaseit(move
ment A ).
Rearscreenwiperbladeontail
gate
– Lift the wiper arm 6 ;
– pull the tab 8 (movement B ) and
push the blade 7 upwards.
